Pulse-code modulation (PCM) is the raw digital representation of audio, crucial for features such as voice chat, low-latency alerts, radio apps, or real-time audio feedback in mobile apps. In React Native, standard packages (e.g. expo-av) don’t support “raw” PCM streaming. Managed Expo Go apps cannot use arbitrary native modules, but expo-dev-client removes this limitation, letting you add native code and bridge native audio libraries—including those that support PCM buffers.

For practical use cases like:

Live voice chat streaming
Receiving and playing server-pushed PCM alerts
Audio processing or instrumentation apps

…it is essential to handle low-level PCM playback directly. This tutorial will walk you through setting up, coding, and troubleshooting PCM streaming using expo-dev-client and the react-native-pcm-audio package. You’ll find actionable instructions, code samples, and best practices, drawn from open-source documentation and real case studies.

Preparing Your React Native Project for PCM Audio Streaming

1. Setting Up the Project

Start by creating a new Expo project and setting it up for native development, which is required for PCM playback using native modules.

Bash
1npx create-expo-app my-pcm-audio-app
2cd my-pcm-audio-app
3npx expo install expo-dev-client
4npx expo prebuild    # Converts to bare workflow, adds ios and android folders
5

Note: expo prebuild is necessary if your project is in the managed workflow. It adds the /ios and /android folders you need for native code.

2. Installing Native Dependencies

Next, add the PCM audio module:

Bash
1npm install react-native-pcm-audio
2# or
3yarn add react-native-pcm-audio
4

Link and Configure

On iOS: run npx pod-install
On Android: open Android Studio and ensure the module appears under native dependencies

3. Building Your Custom Dev Client

expo-dev-client allows you to run your app with any native code. You must always launch your app using your custom client, not Expo Go:

Bash
1npx expo run:android   # On Android
2npx expo run:ios       # On iOS (requires macOS/Xcode)
3

4. Troubleshooting Native Integration

If you encounter errors:

Double-check you’re running your built dev client, not Expo Go
Remove node_modules, clean CocoaPods/Gradle:
```
Bash
1rm -rf node_modules ios/Pods
2npm install
3npx pod-install
4
```
For Android, run ./gradlew clean inside the android folder

For more troubleshooting steps, refer to:

Integrating and Using react-native-pcm-audio: Initialization, Playback, and Stream Management

PCM Session Options

PCM playback sessions have plenty of configurable parameters. You will primarily set:

encoding: e.g., '16bit', '8bit', 'float' (see docs)
usage: e.g., 'alarm', 'music', 'voicecall' (used by underlying OS audio APIs)
sampleRate: e.g., 16000 for 16kHz
channels: number of channels, 1 (mono) or 2 (stereo)
mode: 'streaming' (real-time) or 'static' (buffered, play once)

Example: Initializing the Audio Session

Javascript
1import { NativeModules } from 'react-native';
2
3const sessionOptions = {
4  encoding: '16bit',
5  usage: 'alarm',
6  sampleRate: 16000,
7  channels: 1,
8  mode: 'streaming',
9};
10
11function startPcmSession(options) {
12  return new Promise(resolve => {
13    NativeModules.PcmAudio.build(options, (event, data) => {
14      if (event === 'onSessionId') resolve(data);
15    });
16  });
17}
18

Writing PCM Buffers

Audio data should be written in base64-encoded binary form. Here’s how to convert and send audio frames (assuming a Int16Array buffer):

Javascript
1import base64 from 'react-native-base64';
2
3function writePcm(sessionId, int16Array) {
4  const uint8Array = new Uint8Array(int16Array.buffer);
5  const base64Data = base64.encode(String.fromCharCode.apply(null, uint8Array));
6  NativeModules.PcmAudio.write(sessionId, base64Data);
7}
8

Playing and Stopping Audio

Javascript
1NativeModules.PcmAudio.play(sessionId);    // Start playback
2NativeModules.PcmAudio.stop(sessionId);    // Stop playback
3NativeModules.PcmAudio.release(sessionId); // Release audio session
4

Example: Full Streaming Session

Javascript
1let pcmSessionId = null;
2
3async function setupAndPlayPcmStream(getNextPcmBuffer) {
4  pcmSessionId = await startPcmSession(sessionOptions);
5
6  // Playback loop
7  while (true) {
8    const buffer = await getNextPcmBuffer(); // Await PCM frames from stream/network/device
9    if (!buffer) break;
10    writePcm(pcmSessionId, buffer);
11  }
12}
13

Key Notes:

Always match PCM format to session options
Call release(sessionId) when done to free resources

Advanced PCM Streaming Scenarios and Real-World Examples

Case Study: Live Voice Streaming via WebSocket

Suppose your server sends Int16 PCM buffers via WebSocket (e.g., for a push-to-talk app). Here’s how you’d wire that up:

Javascript
1import React, { useRef, useEffect } from 'react';
2
3function VoiceStreamPlayer({ wsUrl }) {
4  const sessionIdRef = useRef(null);
5  useEffect(() => {
6    let ws = new WebSocket(wsUrl);
7
8    startPcmSession(sessionOptions).then(sessionId => {
9      sessionIdRef.current = sessionId;
10      ws.onmessage = ({ data }) => {
11        let pcmData = new Int16Array(data); // adjust as needed
12        writePcm(sessionId, pcmData);
13      };
14    });
15
16    return () => {
17      ws.close();
18      if (sessionIdRef.current) NativeModules.PcmAudio.release(sessionIdRef.current);
19    };
20  }, [wsUrl]);
21
22  return null;
23}
24

Tips:

Ensure network buffers and audio playback are synchronized (avoid underruns)
Consider queueing or pacing if frames arrive too quickly

Playback Mode Comparison

Streaming Mode: Best for ongoing or real-time audio (voice chat, radio)
Static Mode: Best for playing preloaded PCM clips (alerts, notifications)

Javascript
1const staticOptions = { ...sessionOptions, mode: 'static' };
2
3// Writing all buffers first
4startPcmSession(staticOptions).then(sessionId => {
5  buffers.forEach(buffer => writePcm(sessionId, buffer));
6  NativeModules.PcmAudio.play(sessionId);
7});
8

Buffer Conversion for Different Formats

Sometimes PCM arrives as an array buffer; convert as needed:

Javascript
1function arrayBufferToBase64(arrayBuffer) {
2  let binary = '';
3  let bytes = new Uint8Array(arrayBuffer);
4  bytes.forEach(b => (binary += String.fromCharCode(b)));
5  return base64.encode(binary);
6}
7

Real Use: Emergency Broadcast Player

Multiple government apps use server-pushed PCM clips for alerts. A similar flow would:

Open a session on notification
Buffer and play PCM frames as they arrive until the alert ends
Release the session to conserve device battery/memory

Conclusion and Additional Resources

Summary Checklist

Use expo-dev-client for custom native modules
Install and link react-native-pcm-audio
Match PCM buffer format to session configuration (encoding, bit depth, sample rate, channels)
Use streaming for continuous audio, static for alerts/clips
Always release sessions on unmount/finish
Troubleshoot using project logs and double-check custom client builds
